170 degree diagonal macro viewing angle lens with mirror image
Dust and water resistant, IP68
High-resolution colour COMS/CCD image sensor
Distance guideline projection
Night vision
Very easy mounting
Product Specifications
Lens angle: 170 degrees diagonal
Sensing area: NTSC / PAL 4.08 x 3.10 mm
Pixels: 728 (H) * 492 (V)
Horizontal Resolutions: 520 TV lines
White balance: Auto
Minimum Illumination: 0.1 – 0.5Lux / F = 1.2
Video output: RCA connector, 1.0 V p-p, 75ohm
Power supply: DC12V
Operating temperature: -30 °C to + 85 °C, RH 95%
Video cable: 6 m
Power cable: 1.2 m
Compatible with vehicles:
Audi A3 2004-2013
Audi A4 2004-2013
Audi A5 2004-2013
Audi A6 2004-2013
Audi A8 2004-2013
Audi Q7 2003-2009
Audi S4 2003-2009
Audi RS4 2006-2008
Audi S5 2006-2008
Audi Cabrio 2003-2009
IMPORTANT:
The car models specified are for reference only.
Before purchasing, please ensure that our product has the same measurements as the number plate light of the car you wish to mount it on.
The product is not compatible with standard car radios.
IMPORTANT:
If after mounting the video is disturbed (with stripes) or only works with the car switched off, the problem is that the rear view camera does not always receive 12V. In this case, an electrical stabiliser (relay) must be fitted to solve the problem.
The relay can be purchased from the link in the picture below:
Example of pictures where the rear view camera is not correctly powered:
Example of picture before and after relay installation:
